This product has been discontinued, and manufacturer warranty or support may no longer be available.
1035018 | SICK | DRS61-EAB08192
₹ 104,291.52
₹ 88,382.64 (Excl. Tax)
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
1035018 | SICK | DRS61-EAB08192
Manufacturer Part Number (MPN)
DRS61-EAB08192 (1035018)
Original Equipment Manufacturer
SICK SENSORS
Description
Description
The DRS61-EAB08192 is an incremental encoder from SICK's DRS60 series. It features a solid shaft with a face mount flange and offers a maximum resolution of 8,192 pulses per revolution, making it suitable for applications requiring high precision.
- Mechanical Design: Solid shaft with face mount flange
- Shaft Diameter: 10 mm
- Flange Material: Aluminum
- Housing Material: Aluminum die-cast
- Maximum Resolution: 8,192 pulses per revolution
- Operating Speed: Up to 6,000 min⁻¹
-
Permissible Shaft Loading:
- Radial: 80 N
- Axial: 40 N
- Operating Temperature Range: –25 °C to +70 °C
- Supply Voltage: 4.5 V to 32 V
- Output Signal: TTL/HTL programmable
- Short-Circuit Protection: Yes
- MTTFd: 300 years (EN ISO 13849-1)
The DRS61-EAB08192 is ideal for high-precision applications in robotics, CNC machines, and industrial automation systems requiring incremental encoding.
