1485CS-P3N5-M5 | ALLEN BRADLEY | DeviceNet Cable, Stainless Steel, Thick Media, Mini Straight Female to Mini Straight Male, 3 m (9.84 ft), 5-Pin, Grey PVC Jacket
₹ 12,446.90
₹ 10,548.22 (Excl. Tax)
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
Manufacturer Part Number (MPN)
1485CS-P3N5-M5
Original Equipment Manufacturer
ALLEN BRADLEY
Description
Description
Maximize connectivity with the Allen-Bradley 1485CS-P3N5-M5 DeviceNet Cordset. Built to deliver secure connections and reliable performance in industrial networks, this cordset is perfect for high-demand applications.
Technical Specifications:
| Number of Poles: | 5 |
| Degree of Protection (IP), Mounted: | IP67 |
| Number of Pins: | 5 |
| First End Connector Style: | Mini, Straight Female |
| Second End Connector Style: | Mini, Straight Male |
| Number of Conductors: | 5 |
| Enclosure Type Rating: | NEMA 1, 2, 3, 4, 6P, 12, 13; IP67; 1200 psi (8270 kPa) washdown |
| Cable Diameter: | Thick |
| Cable Type: | PVC |
| Material: | Epoxy-Coated Zinc, Gold-Plated Brass Contacts |
| Bend Radius: | 10 x diameter |
| Cable Length: | 3 meters (9.84 feet) |
| Special Characteristic: | Heavy-duty passive cable |
| Assembly Rating: | 300V, 8 A (4 A NEC) |
| Cable Rating: | UL-Type PLTC 300V or CM 75°C (167°F) or AWM style 2464, CSA AWM I/II A/B 80°C (176°F) 300V FT1 |
| Cable Temperature: | 75°C (167°F) |
