1756-HSC | ALLEN BRADLEY | ControlLogix High-Speed Counter Module
₹ 100,063.35
₹ 84,799.45 (Excl. Tax)
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
1756-HSC | ALLEN BRADLEY | ControlLogix High-Speed Counter Module
₹ 84,799.45
Unit price
/
Unavailable
Manufacturer Part Number (MPN)
1756-HSC
Original Equipment Manufacturer
ALLEN BRADLEY
Description
Description
| Specification | Details |
|---|---|
| Catalog Number | 1756-HSC |
| Module Type | ControlLogix High-speed Counter Module |
| Number of Counters | 2 |
| Inputs per Counter | 3 (A, B, Z for gate/reset) |
| Counting Frequency (Max) | 1 MHz |
| Input Frequency (Max) | 1 MHz in counter modes (A input); 500 kHz in rate measurement mode (A input); 250 kHz in encoder mode (A/B inputs, X1 or X4); 70 Hz with filter enabled |
| Input Current (Nominal) | 15 mA |
| Operating Voltage | 5V operations: 4.5...5.5V DC; 12/24V operations: 10...26.4V DC |
| Output Current Rating per Point | 20 mA @ 4.5...5.5V DC; 1.0 A @ 10...31.2V DC |
| Power Dissipation (Max) | 5.6 W @ 60 °C (140 °F) |
| Isolation Voltage | 125V (continuous), basic insulation type, input group-to-backplane; 30V (continuous), basic insulation type, input group-to-input group |
| Operating Temperature | 0 to 60 °C (32 to 140 °F) |
| Certifications | CE, c-UL-us, KC, EAC, RCM |
