1756-OB32 | ALLEN BRADLEY | ControlLogix 32-Point 12/24V DC Source Output Module
₹ 63,122.12
₹ 53,493.32 (Excl. Tax)
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
1756-OB32 | ALLEN BRADLEY | ControlLogix 32-Point 12/24V DC Source ...
₹ 53,493.32
Unit price
/
Unavailable
Manufacturer Part Number (MPN)
1756-OB32
Original Equipment Manufacturer
ALLEN BRADLEY
Description
Description
| Attribute | Value |
|---|---|
| Outputs | 32 (non-isolated) |
| Voltage Category | 10…31V DC source |
| Operating Voltage Range | 10…31.2V DC |
| Current per Point (Max) | 0.5 A |
| Current per Module (Max) | 16 A |
| Off-state Leakage Current (Max) | 1 mA per point |
| On-state Voltage Drop (Max) | 0.5V DC @ 0.5 A |
| Surge Current per Point | 2 A for 10 ms, repeatable every 1 s |
| Power Dissipation (Max) | 8.5 W |
| Thermal Dissipation | 29.0 BTU/hr |
| Isolation Voltage | 50V (continuous), basic insulation type, channel-to-backplane |
| Current Draw @ 5.1V | 250 mA |
| Current Draw @ 24V | 2.5 mA |
| Removable Terminal Block Housing | 1756-TBNH, 1756-TBSH |
| Slot Width | 1 |
| Wire Category | 1 (on signal ports) |
| Enclosure Type | None (open-style) |
| Operating Temperature | 0…60 °C (32…140 °F) |
| Storage Temperature | -40…85 °C (-40…185 °F) |
| Relative Humidity | 5…95% noncondensing |
| Vibration | 2 g @ 10…500 Hz |
| Shock (Operating) | 30 g |
| Shock (Non-operating) | 50 g |
| Certifications | UL, CE, CSA, EAC, RCM, KC |
