1756-PB75R | ALLEN BRADLEY | ControlLogix 75W Redundant DC Power Supply
₹ 113,604.76
₹ 96,275.22 (Excl. Tax)
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
Manufacturer Part Number (MPN)
1756-PB75R
Original Equipment Manufacturer
ALLEN BRADLEY
Description
Description
| Attribute | Value |
|---|---|
| Input Voltage Range | 18…32V DC |
| Nominal Input Voltage | 24V DC |
| Input Power (Max) | 110 W |
| Output Power (Max) | 75 W @ 0…60 °C (32…140 °F) |
| Inrush Current (Max) | 30 A |
| Hold-Up Time | 20 ms |
| Current Capacity @ 1.2V DC | 1.5 A |
| Current Capacity @ 3.3V DC | 4 A |
| Current Capacity @ 5.1V DC | 13 A |
| Current Capacity @ 24V DC | 2.8 A |
| Isolation Voltage | 250V (continuous), Reinforced Insulation Type, Power Input to Backplane; Type tested at 3250V DC for 60 s |
| Weight (Approx.) | 1.45 kg (3.2 lb) |
| Dimensions (HxWxD) | 17.5 x 14.5 x 13.7 cm (6.9 x 5.7 x 5.4 in.) |
| Operating Temperature | 0…60 °C (32…140 °F) |
| Storage Temperature | -40…+85 °C (-40…+185 °F) |
| Relative Humidity | 5…95% non-condensing |
| Vibration | 2 g @ 10…500 Hz |
| Shock (Operating) | 30 g |
| Shock (Non-Operating) | 50 g |
| Certifications | UL, c-UL-us, UKCA, CSA, FM, CE, RCM, KC, EAC, CCC |
