1794-IE4XOE2XT | ALLEN BRADLEY | FLEX I/O 4-Point Analog Output Module, Extended Temperature
₹ 101,338.53
₹ 85,880.11 (Excl. Tax)
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
Manufacturer Part Number (MPN)
1794-IE4XOE2XT
Original Equipment Manufacturer
ALLEN BRADLEY
Description
Description
| Specification | Details |
| Product Type | FLEX™ I/O-XT 4-Channel Analog Input / 2-Channel Analog Output Combination Module |
| Function | Provides 4 analog input channels and 2 analog output channels for integrating analog signals into industrial control systems, designed for extreme temperature environments. |
| Input Signal Range | Selectable per channel: 0…20 mA, 4…20 mA, ±10V, 0…10V, 0…5V, ±5V |
| Output Signal Range | Selectable per channel: 0…20 mA, 4…20 mA, ±10V, 0…10V, 0…5V, ±5V |
| Resolution | 16-bit for both inputs and outputs |
| Conversion Rate | 2.5 ms per channel |
| Accuracy | ±0.1% full scale at 25 °C (77 °F) |
| FlexBus Current | 80 mA at 5V DC |
| Power Dissipation | 2.5 W maximum |
| Thermal Dissipation | 8.5 BTU/hr maximum |
| Operating Temperature | -20 to 70 °C (-4 to 158 °F) |
| Part Number | 1794-IE4XOE2XT |
| Manufacturer | Allen-Bradley |
