1794-OE4XT | ALLEN BRADLEY | Flex 4 Point Analog Output Module, Extended Temperature
₹ 90,232.19
₹ 76,467.96 (Excl. Tax)
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
Manufacturer Part Number (MPN)
1794-OE4XT
Original Equipment Manufacturer
ALLEN BRADLEY
Description
Description
| Attribute | Value |
|---|---|
| Catalog Number | 1794-OE4XT |
| Number of Outputs | 4 single-ended |
| Resolution | 12-bit |
| Output Range | 0...20 mA, 4...20 mA, ±10V, 0...10V, 0...5V |
| Flexbus Current | 50 mA at 5V DC |
| External Power Supply Voltage | 24V DC nominal, 19.2...31.2V DC (includes 5% AC ripple) |
| External Power Supply Current | 110 mA at 24V DC |
| Power Dissipation | 2.5 W |
| Thermal Dissipation | 8.5 BTU/hr |
| Operating Temperature | -20 to 70 °C (-4 to 158 °F) |
| Storage Temperature | -40 to 85 °C (-40 to 185 °F) |
| Relative Humidity | 5% to 95% non-condensing |
| Vibration | 2 g at 10 to 500 Hz |
| Shock (Operating) | 15 g |
| Shock (Non-operating) | 15 g |
| Dimensions (HxWxD) | 46.3 x 53.0 x 94.0 mm (1.82 x 2.09 x 3.70 in.) |
| Enclosure Type Rating | None (open-style) |
| Certifications | UL Listed, CE Marked, c-UL-us, C-Tick, ATEX, KC |
