This product has been discontinued, and manufacturer warranty or support may no longer be available.
1794-OE8H | ALLEN BRADLEY | Flex 8 Point Analog Output Module with HART Pass-through
₹ 331,598.53
₹ 281,015.70 (Excl. Tax)
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
Manufacturer Part Number (MPN)
1794-OE8H
Original Equipment Manufacturer
ALLEN BRADLEY
Description
Description
| Attribute | Value |
|---|---|
| Catalog Number | 1794-OE8H |
| Number of Outputs | 8 single-ended, non-isolated |
| Output Range | 0...20 mA, 4...20 mA, ±10V, 0...10V, 0...5V |
| Resolution | 13 bits (12.5 bits for 4...20 mA) |
| Flexbus Current | 80 mA at 5V DC |
| External Power Supply Voltage | 24V DC nominal, 19.2...31.2V DC (includes 5% AC ripple) |
| External Power Supply Current | 190 mA at 24V DC |
| Power Dissipation | 5.5 W |
| Thermal Dissipation | 18.8 BTU/hr |
| Operating Temperature | 0 to 55 °C (32 to 131 °F) |
| Storage Temperature | -40 to 85 °C (-40 to 185 °F) |
| Relative Humidity | 5% to 95% non-condensing |
| Vibration | 2 g at 10 to 500 Hz |
| Shock (Operating) | 15 g |
| Shock (Non-operating) | 15 g |
| Dimensions (HxWxD) | 46 x 94 x 53 mm (1.8 x 3.7 x 2.1 in.) |
| Enclosure Type Rating | None (open-style) |
| Certifications | UL Listed, CE Marked, c-UL-us, C-Tick, ATEX, KC |
