1794-TB32S | ALLEN BRADLEY | FLEX I/O 32-Point Spring Clamp Terminal Base Unit
₹ 17,214.19
₹ 14,588.30 (Excl. Tax)
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
Manufacturer Part Number (MPN)
1794-TB32S
Original Equipment Manufacturer
ALLEN BRADLEY
Description
Description
| Attribute | Value |
|---|---|
| Catalog Number | 1794-TB32S |
| Termination Type | Spring Clamp |
| Number of I/O Connections | 32 I/O points |
| Common Terminals | 8 |
| +V Terminals | 8 |
| Maximum Voltage Rating | Up to 31.2V DC/AC |
| Current Capacity | 10 A |
| Wiring Category | 2 |
| Purpose | Designed for high-density I/O applications, accommodating 32-point digital modules; spring clamp terminals provide faster and simpler wire installation. |
| Operating Temperature | -20 to 70 °C (-4 to 158 °F) |
| Storage Temperature | -40 to 85 °C (-40 to 185 °F) |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions (HxWxD) | 94 x 94 x 69 mm (3.7 x 3.7 x 2.7 in.) |
| Enclosure Type Rating | None (open-style) |
| Certifications | UL Listed, CE Marked, c-UL-us, ATEX, KC |
