SPARECRUX is NOT an authorized distributor for ALLEN BRADLEY

1794-VHSC | ALLEN BRADLEY | FLEX I/O Very High Speed Counter Module

₹ 103,419.66

₹ 87,643.78 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Manufacturer Part Number (MPN)

1794-VHSC

Original Equipment Manufacturer

ALLEN BRADLEY

Description
Attribute Value
Catalog Number 1794-VHSC
Number of Channels 2
Input Frequency Up to 1 MHz for single-phase inputs; up to 250 kHz for 2-phase encoder inputs in X4 mode
Input Voltage Range 5V or 24V DC
Output Channels 4 (isolated in pairs)
Output Voltage 5V or 12…24V DC
Output Current Capacity 0.5 mA max at 5V; 1 A max at 12…24V
Operating Modes Counter, Encoder (X1, X2, X4), Period/Rate, Continuous/Rate, Rate Measurement, Pulse-Width Modulation (PWM)
Maximum Count Value 16,777,215
Operating Temperature -20 to 70 °C (-4 to 158 °F)
Certifications UL, CE, ATEX, KC
ALLEN BRADLEY

1794-VHSC | ALLEN BRADLEY | FLEX I/O Very High Speed Counter Module

₹ 87,643.78
Attribute Value
Catalog Number 1794-VHSC
Number of Channels 2
Input Frequency Up to 1 MHz for single-phase inputs; up to 250 kHz for 2-phase encoder inputs in X4 mode
Input Voltage Range 5V or 24V DC
Output Channels 4 (isolated in pairs)
Output Voltage 5V or 12…24V DC
Output Current Capacity 0.5 mA max at 5V; 1 A max at 12…24V
Operating Modes Counter, Encoder (X1, X2, X4), Period/Rate, Continuous/Rate, Rate Measurement, Pulse-Width Modulation (PWM)
Maximum Count Value 16,777,215
Operating Temperature -20 to 70 °C (-4 to 158 °F)
Certifications UL, CE, ATEX, KC
