Sold out
2085-IF8K | ALLEN BRADLEY | Micro800 8-Channel Analog Input Module, CC
₹ 46,704.14
₹ 39,579.78 (Excl. Tax)
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
Manufacturer Part Number (MPN)
2085-IF8K
Original Equipment Manufacturer
ALLEN BRADLEY
Description
Description
Technical Data for Allen-Bradley 2085-IF8K
| Specification | Details |
| Product Type | Micro800 8-Channel Analog Input Module with Conformal Coating |
| Number of Inputs | 8 |
| Input Signal Types | Voltage: ±10V, 0…10V; Current: 0…20 mA, 4…20 mA |
| Resolution | 14 bits |
| Conversion Time | ~500 ms per channel |
| Input Impedance | Voltage: >1 MΩ; Current: 250 Ω |
| Accuracy | ±0.5% of full scale at 25°C |
| Isolation Voltage | 250V (continuous), Reinforced Insulation Type, channel to system |
| Power Consumption | 5V DC, 110 mA; 24V DC, 120 mA |
| Operating Temperature Range | -20…65°C (-4…149°F) |
| Storage Temperature Range | -40…85°C (-40…185°F) |
| Relative Humidity | 5…95% non-condensing |
| Dimensions (H x W x D) | 90 mm x 44.5 mm x 87 mm (3.54 in. x 1.75 in. x 3.43 in.) |
| Mounting | DIN rail or panel mount |
| Certifications | c-UL-us Listed; CE Marked; RCM; KC |
