6041819 | SICK | VL180-2P42431
₹ 5,703.65
₹ 4,833.60 (Excl. Tax)
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
6041819 | SICK | VL180-2P42431
Manufacturer Part Number (MPN)
VL180-2P42431 (6041819)
Original Equipment Manufacturer
SICK SENSORS
Description
Description
The VL180-2P42431 is a cylindrical photoelectric sensor from SICK's V180-2 series, designed for retro-reflective sensing applications. It features a sensing range of up to 7 meters with the appropriate reflector and is suitable for various industrial environments.
- Housing Diameter: 18 mm
- Housing Length: 70.2 mm
- Thread Diameter: M18 x 1
- Optical Axis: Axial
- Sensing Range: 0.05 m to 7 m (with reflector)
- Focus: Approx. 4.5°
- Light Source: Visible red light (LED, 645 nm)
- Adjustment: Potentiometer, 270° (Sensitivity)
- Supply Voltage (UB): 10 V DC to 30 V DC
- Ripple: ± 10%
- Current Consumption: 30 mA
- Switching Output: PNP
- Switching Mode: Light/dark switching
- Switching Mode Selector: Selectable via L/D control cable
- Signal Voltage (PNP HIGH/LOW): Approx. VS – 1.8 V / 0 V
- Output Current (Imax.): ≤ 100 mA
- Response Time: ≤ 0.5 ms
- Switching Frequency: 1,000 Hz
- Connection Type: Male connector M12, 4-pin
- Circuit Protection: Reverse-polarity protected, overcurrent and short-circuit protected
- Protection Class: III
- Weight: 47 g
- Polarization Filter: Yes
- Housing Material: Metal, Nickel-plated brass and PC
- Optics Material: Plastic, PMMA
- Enclosure Rating: IP67
- Ambient Operating Temperature: –25 °C to +55 °C
- Ambient Temperature, Storage: –40 °C to +70 °C
- UL File No.: NRKH2.E300503 & NRKH8.E300503
The VL180-2P42431 is ideal for applications requiring long-range detection with background suppression, such as in material handling, sorting, and packaging systems.
