SPARECRUX is an authorized distributor for CONNECTWELL

CSR1S-24DYB | CONNECTWELL | 1CO 24VDC Single Channel Slim Relay Module With Plug-able Relay Rail Mount

₹ 372.88

₹ 316.00 (Excl. Tax)

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Manufacturer Part Number (MPN)

CSR1S-24DYB

Original Equipment Manufacturer

CONNECTWELL

Description
  1. Compact 6.0mm thin design.
  2. Variety of Operating Voltages.
  3. High switching current: up to 6A at 250VAC
  4. Low coil power consumption: 175 mW.
  5. LED Indication on Coil activation.
  6. No requirement on polarity of input voltage (except 5 VDC &24VDC Relay).
  7. Possibility of Jumpering up to 8 channels with a single link.
  8. Easy Legibility marker
  9. Choice of Pluggable Electromechanical Relays Or Solid State Relays.
  10. Choice of Screw & Spring Clamp Connection
  11. Special Snubber based Slim Relays are Available.
  12. Integrated Input Protection.

  13. UL, CE Approvals, ROHS Complient

Technical Data

Bussing Possiblity By Push in type shorting link
Relay on Indication 3mm Green LED
Ambient Operating Temperature -40 to +55 °C
Mounting Possibility DIN 35/DIN 35-15 Rail
Housing Material PA 6,6
Housing Colour Grey
Rated Voltage 24 VDC
Input Polarity Protection Reverse Polarity Protection, Rectifier based Protection.
Relay type Electromechanics
