DK 0100 G | HENSEL | Cable junction box
₹ 330.40
₹ 280.00 (Excl. Tax)
● Available for backorder, with an estimated lead time of 8 to 12 weeks.
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
DK 0100 G | HENSEL | Cable junction box
₹ 280.00
Unit price
/
Unavailable
Manufacturer Part Number (MPN)
DK 0100 G
Original Equipment Manufacturer
HENSEL ELECTRIC
Description
Description
DK 0100 G
- without terminals
- with integrated elastic membranes, which can be removed for cable entry via cable glands, sealing range 6.0-15.0 mm
- with one cable entry in the bottom, sealing range Ø 6.0-13.0 mm
- lid fasteners sealable without accessories
- external brackets for wall fixing included
- colour: grey, RAL 7035
- To close opened membranes use grommets type EDK. Degree of protection = IP 66.
Technical Data
| rated insulation voltage | Ui = 1000 V a.c./d.c. |
| material | PP (polypropylene) |
| degree of protection | IP 66 |
| mounting width | 65 mm |
| mounting height | 65 mm |
| max. installation depth | 40 mm |
| width | 84 mm |
| height | 84 mm |
| depth | 55 mm |
| weight | 0,087 kg |
| in accordance with | IEC 60670-22 |
