SPARECRUX is an authorized distributor for HENSEL ELECTRIC

DK 0604 V | HENSEL | Cable Junction Boxes IP 66 With PE Inlay

₹ 1,873.84

₹ 1,588.00 (Excl. Tax)

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Manufacturer Part Number (MPN)

DK 0604 V

Original Equipment Manufacturer

HENSEL ELECTRIC

Description

DK 0604 V

  • 1.5-4 mm², Cu 3~
  • Terminal with 2 clamping units per pole
  • 5-pole per pole 8 x 1,5 mm² r / f, 6 x 2,5 mm² r / f, 4 x 4 mm² r / f, 2 x 6 mm² r / f
  • With patented PE inlay to connect the armours of SWA cables
  • With elastic membranes, which can be removed for cable entry via cable glands, sealing range 9.0-21.0 mm
  • Lid fasteners sealable without accessories
  • Retaining strap and external brackets for wall fixing included
  • Colour: black, RAL 9011
  • To close opened membranes use grommets type EDK. Degree of protection = IP 66.

Technical Data

rated insulation voltage Ui = 690 V A.C./D.C.
rated current: 32 A
material PP (polypropylene)
degree of protection IP 66
width 130 mm
height 130 mm
depth 77 mm
weight 0,339 kg
tightening torque for terminal 0.7 Nm
in accordance with IEC 60670-22

Dk 0604 V | Hensel Cable Junction Boxes Ip 66 With Pe Inlay
HENSEL ELECTRIC

DK 0604 V | HENSEL | Cable Junction Boxes IP 66 With PE Inlay

₹ 1,588.00

DK 0604 V

  • 1.5-4 mm², Cu 3~
  • Terminal with 2 clamping units per pole
  • 5-pole per pole 8 x 1,5 mm² r / f, 6 x 2,5 mm² r / f, 4 x 4 mm² r / f, 2 x 6 mm² r / f
  • With patented PE inlay to connect the armours of SWA cables
  • With elastic membranes, which can be removed for cable entry via cable glands, sealing range 9.0-21.0 mm
  • Lid fasteners sealable without accessories
  • Retaining strap and external brackets for wall fixing included
  • Colour: black, RAL 9011
  • To close opened membranes use grommets type EDK. Degree of protection = IP 66.

Technical Data

rated insulation voltage Ui = 690 V A.C./D.C.
rated current: 32 A
material PP (polypropylene)
degree of protection IP 66
width 130 mm
height 130 mm
depth 77 mm
weight 0,339 kg
tightening torque for terminal 0.7 Nm
in accordance with IEC 60670-22
