K 0101 | HESNEL | Empty Box IP66
₹ 4,144.16
₹ 3,512.00 (Excl. Tax)
● Available for backorder, with an estimated lead time of 8 to 12 weeks.
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
K 0101 | HESNEL | Empty Box IP66
₹ 3,512.00
Unit price
/
Unavailable
Manufacturer Part Number (MPN)
K 0101
Original Equipment Manufacturer
HENSEL ELECTRIC
Description
Description
K 0101
- Built-in dimensions W 275 x H 125 x D 150 mm
- Enclosure size 1, type Mi
- For installation equipment on DIN rails or mounting plates (order separately)
- Max. installation depth with built-in mounting plate 146 mm,
with built-in DIN rail 135 mm - With opaque lid
- Lid fasteners for tool operation
- Sealable
- Box walls without knockouts
- Optional hinges for device installation in the lid
- External brackets for wall fixing as accessories
- Colour: Grey, RAL 7035
- Material: PC (polycarbonate)
Technical Data
| Rated insulation voltage | Ui = 690 V A.C. / 1000 V D.C. |
| Impact strength | IK 08 (5 Joule) |
| Static load | Mounting plate or DIN rail = 3.2 kg lid = 1.3 kg |
| Power dissipation capability at Δϑ = 40 K | Pde = 33 watts |
| Wall thickness | Enclosure = 3 mm lid = 3 mm |
| Material | PC (Polycarbonate) |
| Degree of protection | IP 66 |
| Mounting width | 275 mm |
| Mounting height | 125 mm |
| Max. installation depth | 146 with built-in mounting plate mm |
| Max. installation depth | 135 with built-in DIN rail mm |
| Width | 300 mm |
| Height | 150 mm |
| Depth | 170 mm |
| Weight | 1,38 kg |
| In accordance with |
IEC 62208:2011 |
